meySPAN H3V is a high-performance core-treated LVL developed for exposed, above-ground environments. With H3 treatment in every veneer, meySPAN H3V delivers full-depth protection against decay and termites, meaning no need to retreat cut ends on-site, although end sealing is always recommended.
Available in smaller, easy-to-handle pack sizes designed for merchant racking. Reliable, straight, and built for demanding conditions, meySPAN H3V sets a new benchmark for outdoor structural LVL.
Engineered for demanding outdoor builds, meySPAN H3V is suited to deck bearers and joists, veranda beams, rafters, and any above-ground structural application requiring long-term strength and full-depth H3 protection.
SPECIFICATIONS:
- H3 Core Treated: Every veneer layer is treated for consistent, full-depth protection.
- Cut Ends: No Retreatment required. End Sealing Recommended.
- Smaller Pack Sizes: Easier handling, safer lifting, and efficient storage in merchant racks.
- Weather Shield+ Coating: Moisture-resistant, anti-mould, and UV-protected for extended durability.
- Stable & Straight: Minimises warping, twisting, bowing, and movement over time.
- Outdoor Structural Ready: Ideal for deck bearers and joists, veranda beams, rafters, and other above-ground external applications.
NSW / QLD:
| SIZE | PACK QUANTITY | LENGTH (M) |
| 150×45 | 20 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 150×63 | 15 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 200×45 | 12 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 200×63 | 9 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 240×45 | 12 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 240×63 | 9 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 300×45 | 8 Pieces | 4.8, 5.4, 6.0, 7.2 |
| 300×63 | 6 Pieces | 4.8, 5.4, 6.0, 7.2 |
VIC / TAS:
| SIZE | LENGTH (M) |
| 90×45 | 3.6, 4.8, 6.0, 7.2 |
| 140×45 | 3.6, 4.8, 6.0, 7.2 |
| 190×45 | 3.6, 4.8, 6.0, 7.2 |
| 240×45 | 3.6, 4.8, 6.0, 7.2 |
| 300×45 | 3.6, 4.8, 6.0, 7.2 |
meySPAN H3V is a high-performance, core-treated LVL for exposed, above-ground applications. With every veneer H3 treated, it offers full-depth protection against decay and termites, eliminating the need to retreat cut ends on-site, although end sealing is always recommended. Available in smaller, easy-to-handle pack sizes for merchant racking, meySPAN H3V is reliable, straight, and built for demanding outdoor conditions.
Contact your local supplier for stock availability and custom sizing.
For more information regarding Installation, Storage and Handling and Best Practices, Refer to our Specification and User Guide.
